ENGLISH
5 WORKING RANGE
5.1 POWER SUPPLY WORKING RANGE
Nominal power supply
• Single phase: 1~ 230V 50Hz
• Three phase: 3N~ 400V 50Hz
Operating voltage
Between 90 and 110% of the nominal voltage.
Voltage imbalance for nominal power supply 3N~ 400V 50Hz
Up to 3% of each phase, measured at the main terminal of the outdoor unit.
Starting voltage
Always higher than 85% of the nominal voltage.
5.2 R410A TEMPERATURE WORKING RANGE
MODEL 2.0HP 2.5HP 3.0HP 4.0HP 5.0HP 6.0HP 8.0HP 10.0HP
Water temperature
ºC
Refer to the graphics for each case
Indoor ambient temperature 5~30
5.2.1 Space heating
YUTAKI (S / S COMBI)
(4.0-10.0)HP
Water outlet
temperature (Cº)
Ambient temperature
(ºC (DB))
Continuous working range.
Outdoor unit operation is possible, but the capacity is not guaranteed. Indoor unit and back-up heater are operating.
Only back-up heater. (No outdoor unit operation).
WORKING RANGE
PMML0575 rev.2 - 03/2022
31
