Split system - Indoor unit
YUTAKI S
Model Power supply Operation mode
Max.
current
(A)
Power supply
cables
Transmitting
cables
Actuator
cables
EN60335-1 EN60335-1 EN60335-1
RWM-(2.0-3.0)R1E 1~ 230V 50Hz
Without electric heaters 0.6 2 x 0.75 mm² + GND
2 x 0.75 mm
2
(Shielded
cable)
2 x 0.75
mm
2
+ GND
With electric heater 14 2 x 2.5 mm² + GND
With DHW tank heater 14 2 x 2.5 mm² + GND
With electric and DHW tank heaters 27 2 x 6.0 mm² + GND
RWM-(2.0-3.0)R1E 3N~ 400V 50Hz
Without electric heaters
0.6 4 x 0.75 mm² + GND
With electric heater 5.0 4 x 2.5 mm² + GND
With DHW tank heater 14 4 x 2.5 mm² + GND
With electric and DHW tank heaters
18.0 4 x 6.0 mm² + GND
RWM-(4.0-6.0)N1E
1~ 230V 50Hz
Without electric heaters 0.7 2 x 0.75 mm² + GND
With electric heater 27 2 x 6.0 mm² + GND
With DHW tank heater 14 2 x 2.5 mm² + GND
With electric and DHW tank heaters
40 2 x 10.0 mm² + GND
3N~ 400V 50Hz
Without electric heaters 0.7 4 x 0.75 mm² + GND
With electric heater 9 4 x 2.5 mm² + GND
With DHW tank heater 14 4 x 2.5 mm² + GND
With electric and DHW tank heaters 22 4 x 6.0 mm² + GND
RWM-(8.0/10.0)N1E 3N~ 400V 50Hz
Without electric heaters 0.7 4 x 0.75 mm² + GND
With electric heater 14 4 x 4.0 mm² + GND
With DHW tank heater 14 4 x 4.0 mm² + GND
With electric and DHW tank heaters 27 4 x 10.0 mm² + GND
? NOTE
The data corresponding to DHW tank heater is calculated in combination with the domestic hot water tank accessory “DHWT-(200/300)S-3.0H2E”.
YUTAKI S COMBI
Model Power supply Operation mode
Max.
current
(A)
Power supply
cables
Transmitting
cables
Actuator
cables
EN60335-1 EN60335-1 EN60335-1
RWD-(2.5-3.0)RW1E-
220S(-K)
1~230V 50Hz
Without electric heaters 0.6
2 x 0.75 mm² + GND
2 x 0.75 mm
2
(Shielded
cable)
2 x 0.75 mm
2
+ GND
With electric heater 13.7
2 x 2.5 mm² + GND
With DHW tank heater 12.6
2 x 2.5 mm² + GND
With electric and DHW tank heaters 25.6
2 x 6.0 mm² + GND
RWD-(2.5-3.0)RW1E-
220S(-K)
3N~400V 50Hz
Without electric heaters 0.6
4 x 0.75 mm² + GND
With electric heater 9.3
4 x 2.5 mm² + GND
With DHW tank heater 12.6
4 x 2.5 mm² + GND
With electric and DHW tank heaters 12.6
4 x 2.5 mm² + GND
RWD-(4.0-6.0)NW1E-
220S(-K)
1~230V 50Hz
Without electric heaters 0.7
2 x 0.75 mm² + GND
With electric heater 26.7
2 x 6.0 mm² + GND
With DHW tank heater 12.6
2 x 2.5 mm² + GND
With electric and DHW tank heaters 38.7
2 x 10.0 mm² + GND
3N~400V 50Hz
Without electric heaters 0.7
4 x 0.75 mm² + GND
With electric heater 18.0
4 x 6.0 mm² + GND
With DHW tank heater 12.6
4 x 2.5 mm² + GND
With electric and DHW tank heaters 18.0
4 x 6.0 mm² + GND
ELECTRICAL AND CONTROL SETTINGS
