Hitachi YUTAKI Series Service Manual

Servicing
Service Manual
240
RHUE-(3~6)A(V)HN
SMGB0066 rev.0 - 12/2009
 
Removethenine(9)screwsxingtheuppercover1.
Lift the upper cover upwards.2.
 

Removethefour(4)xingscrewsatthelowerpart1.
of the service panel and remove the lower part of
the service panel by pulling towards the front side.
Removethexingscrewsoftherearpaneland
remove the rear panel.

note
The length of xing scews for the Yutaki temperature -
thermistor is different than all other screws in the machine,
as an assembly poka-yoke.
Upper cover
The lower part of service panel Rear panel
