RHUE-(3~6)A(V)HN
SMGB0066 rev.0 - 12/2009
Servicing
Service Manual
9
Remove the service cover according to the section 1.
“Removing service cover” in this chapter.
Collecttherefrigerantfromthecheckjointaccordingto2.
the section “Removing the compressor” in this chapter.
Disconnect the faston terminals from the pressure 3.
switch.
Cut the high pressure switch from the brazing neck -
using a burner.
warning
High pressures. Explosion risk. -
Do not change the high pressure switch locally or -
change the high pressure cut-out set value locally. If
changed, it will cause serious injury or death due to
explosion.
Do not attempt to turn service valve rod beyond its stop. -
High pressure
switch
Terminals
High pressure switch structure
Contact point
Pressure detection
Faston terminals
