Table 12: The Status: DOCSIS WAN Screen
DOCSIS Overview
CM Configurator file
name
This displays the name of the configuration file that the
CGNV downloaded from your service provider. This file
provides the CGNV with the service parameter data that
it needs to perform its functions correctly.
Network Access This displays whether or not your service provider
allows you to access the Internet over the CABLE
connection.
Permitted displays if you can access the Internet.
Denied displays if you cannot access the Internet.
IP Address This displays the CGNV’s WAN IP address. This IP
address is automatically assigned to the CGNV
Subnet Mask This displays the CGNV’s WAN subnet mask.
Gateway IP This displays the IP address of the device to which the
CGNV is connected over the CABLE interface.
DHCP Lease Time This displays the time that elapses before your device’s
IP address lease expires, and a new IP address is
assigned to it by the DHCP server.
Downstream Overview
NOTE: The downstream signal is the signal transmitted to the CGNV.
Port ID This displays the ID number of the downstream
connection’s port.
Frequency (MHz) This displays the actual frequency in Megahertz (MHz)
of each downstream data channel to which the CGNV is
connected.
Modulation This displays the type of modulation that each
downstream channel uses.
Signal Strength
(dBmV)
This displays the power of the signal of each
downstream data channel to which the CGNV is
connected, in dBmV (decibels above/below 1 millivolt).
Signal Noise Ratio
(dB)
This displays the Signal to Noise Ratio (SNR) of each
downstream data channel to which the CGNV is
connected, in dB (decibels).
Channel ID This displays the ID number of each channel on which
the downstream signal is transmitted.
