3.5 The DOCSIS Event Screen
Use this screen to view information about the CGNV’s wireless network.
Click Status > DOCSIS Event. The following screen displays.
Upstream Overview
NOTE: The upstream signal is the signal transmitted from the CGNV.
Port ID This displays the ID number of the upstream
connection’s port.
Frequency (MHz) This displays the actual frequency in Megahertz (MHz)
of each upstream data channel to which the CGNV is
connected.
Modulation This displays the type of modulation that each upstream
channel uses.
Signal Strength
(dBmV)
This displays the power of the signal of each upstream
data channel to which the CGNV is connected, in dBmV
(decibels above/below 1 millivolt).
Signal Noise Ratio
(dB)
This displays the Signal to Noise Ratio (SNR) of each
upstream data channel to which the CGNV is
connected, in dB (decibels).
Channel ID This displays the ID number of each channel on which
the upstream signal is transmitted.
Table 12: The Status: DOCSIS WAN Screen (continued)
