Hitron CGNV User’s Guide
4.6 The Port Triggering Screen
Use this screen to configure port triggering. You can turn port triggering on or off and
configure new and existing port triggering rules.
Protocol Use this field to specify whether the CGNV should
forward traffic via:
Transmission Control Protocol (TCP)
User Datagram Protocol (UDP)
Transmission Control Protocol and User Datagram
Protocol (TCP/UDP)
Generic Routing Encapsulation (GRE)
Encapsulating Security Protocol (ESP)
NOTE: If in doubt, leave this field at its default (TCP/
UDP).
Public Port Range Use these fields to specify the incoming port range.
These are the ports on which the CGNV receives traffic
from the originating host on the WAN.
Enter the start port number in the first field, and the end
port number in the second field.
To specify only a single port, enter its number in both
fields.
Private Port Range Use these fields to specify the ports to which the
received traffic should be forwarded.
Enter the start port number in the first field. The number
of ports must match that specified in the Public Port
Range, so the CGNV completes the second field
automatically.
Local IP Address Use this field to enter the IP address of the computer on
the LAN to which you want to forward the traffic.
Apply Click this to save your changes to the fields in this
screen.
Close Click this to return to the Port Forwarding screen
without saving your changes to the port forwarding rule.
Table 19: The Basic: Port Forwarding Add/Edit Screen
