Honda BF40D - Page 304

11-42
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Pinion gear shim selection table
[2] Tolerance
+0.15 (+0.006) +0.20 (+0.008) +0.25 (+0.010) +0.30 (+0.012) +0.35 (+0.014) +0.40 (+0.016)
------
+0.20 (+0.008) +0.25 (+0.010) +0.30 (+0.012) +0.35 (+0.014) +0.40 (+0.016) +0.45 (+0.018)
A 0.95 (0.037) 1.00 (0.039) 1.05 (0.041) 1.10 (0.043) 1.15 (0.045) 1.20 (0.047)
B 0.90 (0.035) 0.95 (0.037) 1.00 (0.039) 1.05 (0.041) 1.10 (0.043) 1.15 (0.045)
C 0.85 (0.033) 0.90 (0.035) 0.95 (0.037) 1.00 (0.039) 1.05 (0.041) 1.10 (0.043)
D 0.80 (0.032) 0.85 (0.033) 0.90 (0.035) 0.95 (0.037) 1.00 (0.039) 1.05 (0.041)
E 0.75 (0.030) 0.80 (0.032) 0.85 (0.033) 0.90 (0.035) 0.95 (0.037) 1.00 (0.039)
F 0.70 (0.028) 0.75 (0.030) 0.80 (0.032) 0.85 (0.033) 0.90 (0.035) 0.95 (0.037)
[1] Engagement
mark on the gear case
[3] Unit: mm (in)
[2] Tolerance
- 0.15 ( - 0.006) - 0.10 ( - 0.004) - 0.05 ( - 0.002) 0.00 (0.000) +0.05 (+0.002) +0.10 (+0.004)
------
- 0.10 ( - 0.004) - 0.05 ( - 0.002) 0.00 (0.000) +0.05 (+0.002) +0.10 (+0.004) +0.15 (+0.006)
A 0.65 (0.026) 0.70 (0.028) 0.75 (0.030) 0.80 (0.032) 0.85 (0.033) 0.90 (0.035)
B 0.60 (0.024) 0.65 (0.026) 0.70 (0.028) 0.75 (0.030) 0.80 (0.032) 0.85 (0.033)
C 0.55 (0.022) 0.60 (0.024) 0.65 (0.026) 0.70 (0.028) 0.75 (0.030) 0.80 (0.032)
D 0.50 (0.020) 0.55 (0.022) 0.60 (0.024) 0.65 (0.026) 0.70 (0.028) 0.75 (0.030)
E 0.45 (0.018) 0.50 (0.020) 0.55 (0.022) 0.60 (0.024) 0.65 (0.026) 0.70 (0.028)
F 0.40 (0.016) 0.45 (0.018) 0.50 (0.020) 0.55 (0.022) 0.60 (0.024) 0.65 (0.026)
[1] Engagement
mark on the gear case
[3] Unit: mm (in)
[2] Tolerance
- 0.45 ( - 0.018) - 0.40 ( - 0.016) - 0.35 ( - 0.014) - 0.30 ( - 0.012) - 0.25 ( - 0.010) - 0.20 ( - 0.008)
------
- 0.40 ( - 0.016) - 0.35 ( - 0.014) - 0.30 ( - 0.012) - 0.25 ( - 0.010) - 0.20 ( - 0.008) - 0.15 ( - 0.006)
A 0.35 (0.014) 0.40 (0.016) 0.45 (0.018) 0.50 (0.020) 0.55 (0.022) 0.60 (0.024)
B 0.30 (0.012) 0.35 (0.014) 0.40 (0.016) 0.45 (0.018) 0.50 (0.020) 0.55 (0.022)
C 0.25 (0.010) 0.30 (0.012) 0.35 (0.014) 0.40 (0.016) 0.45 (0.018) 0.50 (0.020)
D 0.20 (0.008) 0.25 (0.010) 0.30 (0.012) 0.35 (0.014) 0.40 (0.016) 0.45 (0.018)
E 0.15 (0.006) 0.20 (0.008) 0.25 (0.010) 0.30 (0.012) 0.35 (0.014) 0.40 (0.016)
F 0.10 (0.004) 0.15 (0.006) 0.20 (0.008) 0.25 (0.010) 0.30 (0.012) 0.35 (0.014)
[1] Engagement
mark on the gear case
[3] Unit: mm (in)
304
