Honda BF40D - Page 736

19-12
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
• REMOTE CONTROL TYPE [Side mount remote control box]
WIRING DIAGRAM:
[11]
COMBINATION
SWITCH
[10]
WARNING
BUZZER
[12]
INDICATOR
LIGHT
[8]
POWER TILT/TRIM
SWITCH [POWER
TRIM/TILT TYPE
ONLY]
[9]
EMERGENCY
STOP SWITCH
[8]
POWER TILT/TRIM SWITCH
[POWER TRIM/TILT TYPE
ONLY]
[1]
INDICATOR WIRE
[EQUIPPED TYPE ONLY]
[13]
REMOTE CONTROL CABLE A
[EQUIPPED TYPE ONLY]
[14]
REMOTE CONTROL
CABLE B
[14]
REMOTE
CONTROL
CABLE B
[2]
METER
HARNESS A
[EQUIPPED
TYPE ONLY]
1
7
2
4
5
6
[15] [16]
Terminal Wire
number color
C111 Bl
C112 Y
C113 R
C114 Bl/Y
C115 Bl
[15] [16]
Terminal Wire
number color
C106 W/Bl
C107 Lg
C108 Lb
[15] [16]
Terminal Wire
number color
C118 Bl
C119 Lg/Bl
C120 Gr
C121 Y/Bu
C122 Bl/Y
C123 R
C124 Y
C125 Br
7
4
5
6
[14]
REMOTE
CONTROL
CABLE B
[8]
POWER TILT/TRIM
SWITCH [POWER
TRIM/TILT TYPE
ONLY]
[10]
WARNING BUZZER
[2]
METER HARNESS A
[EQUIPPED TYPE ONLY]
[7]
TO METER
HARNESS B
[OPTIONAL PART]
[4]
TO LIGHTING
SWITCH
[14]
REMOTE
CONTROL
CABLE B
[14]
REMOTE
CONTROL
CABLE B
[12]
INDICATOR
LIGHT
[12]
INDICATOR
LIGHT
[11]
COMBINATION
SWITCH
[9]
EMERGENCY
STOP SWITCH
[11]
COMBINATION
SWITCH
[10]
WARNING
BUZZER
[12]
INDICATOR
LIGHT
[9]
EMERGENCY
STOP SWITCH
[14]
REMOTE
CONTROL
CABLE B
[17]
REMOTE CONTROL
CABLE B
[GAS ASSISTED
TYPE ONLY]
[15] [16]
Terminal Wire
number color
C101 Y/G
C102 Bl/W
C103 Bl/R
C104 Bl/R
C105 W/Bl
C106 W/Bl
C107 Lg
C108 Lb
C109 Bl
C110 Bl/Y
C116 R/Bu
C117 W/Bu
C126 Bl/Y
C127 Bl
[3]
FUSE
(10A)
[6]
TRIM METER
[EQUIPPED TYPE ONLY]
[5]
TACHOMETER
[EQUIPPED TYPE ONLY]
736
