CAUTION
RISK OF PRODUCT DAMAGE
l Protect the detector from physical damage (forklifts, scaffolding, etc.).
l Failure to follow all warnings cautions, and instructions may void the warranty.
l Clean detector body and window with a damp cloth.
l Some regulatory agencies requires the use of hazardous area approved plugs, follow local
rules.
l To maintain IP66/67 integrity, seal on conduit entries with thread sealant such as Loctite 565.
l Do not install in an area where there are incidents of high mechanical damage.
WARNING
RISK OF EXPLOSION
l Ensure power is off and no hazardous gasses nor dusts are present before installing the
device.
l Use only hazardous location approved plugs M25 or ¾ ’’ NPT as marked on product.
SPECIFIC CONDITIONS OF USE:
WARNING
ELECTROSTATIC HAZARD, DO NOT RUB WITH DRY CLOTH
l Contact the manufacturer for dimensional information on the flameproof joint specifications
if repair is required.
Nameplate Tag
Representative Markings are displayed in the figure below.
Additional regional marks (such as South Korea and Russia) and installation specific marks (such as
ABS) may also be present. See individual nameplates for specific approvals applicable to each
product.
Note: Some products require 18 in. of conduit. (See individual nameplate for specifics).
Honeywell®FS24XPlus™ | User Manual
29
