Command #142: Read All Sensor Readings
Reads All Sensor Readings.
Request Data Bytes
Byte Format Description
None
Response Data Bytes
Byte Format Description
0-59 Integer
Optical Sensor Data [0] - [15]
Optical Sensor Data Representation:
0-3 Long Band PBSE DCA VALUE
4-7 Long Band PBSE DCB VALUE
8-11 Long Bande PBSE AC VALUE
12-15 Wide Band PBSE DCA VALUE
16-19 Wide Band PBSE DCB VALUE
20-23 Wide Band PBSE AC VALUE
24-27 NEAR IR Band DC VALUE
28-31 NEAR IR Band AC VALUE
32-35 Visible Band DC VALUE
36-39 Visible Band AC VALUE
40-43 5V Monitoring
44-47 3V3_Safe Monitoring
48-51 AINCOM Monitoring
52-55 UV Count
56-59 u32_channel_status
Command-Specific Response Codes
Code Class Description
0 Success No Command-Specific Errors
1-7 Undefined
8 Error Access Restricted
9-15 Undefined
16 Error Access Restricted
17-127 Undefined
