WARNING
RISK OF EXPLOSION
USE TEST LAMP MODEL TL-1055 IN NON-HAZARDOUS LOCATIONS ONLY.
FOR HAZARDOUS LOCATIONS, USE MODEL TL-2055
Some of the most important functions of the remote test lamp ensure:
l The detector’s optical path is not blocked.
l The detector is appropriately aimed at the fire threat area.
l The detector’s alarming circuitry and outputs (i.e., relays, 4-to-20 mA, etc.) function properly.
Tests are made using the Honeywell® TL-2055 Test Lamp with a range of 10-25 ft when fully
charged.
Wait a minimum of thirty (30) seconds between tests (i.e., test lamp or test fires) to allow the
Detector’s sensors to normalize to the spectral background conditions fully.
WARNING: The following conditions may have a detrimental effect on detector performance or
increase the change of nuisance alarms and therefore should be avoided:
1. Locations where the detector is aimed directly at the sun.
2. Situations where the detector is continuously subjected to modulated sunlight.
Maintenance
After the FS24XPlus™ Flame detector is installed and commissioned, the detector’s window must be
kept clean. To ensure the detector is operating properly at all times, it may be necessary to establish
a periodic cleaning schedule. Inspect at least quarterly in dirty environments. Semi-annual or
quarterly testing should be performed, using the appropriate Honeywell® Test Lamp, to ensure the
integrity of the detector. A complete “end-to-end” test of the entire fire detection system should be
performed periodically depending on the application.
Honeywell®FS24XPlus™ | User Manual
41
