Honeywell® FS24XPlus™ | User Manual
98
Tables
Engineering Unit Type Codes / PV Unit Codes
Code Description Note
39 Milliamperes Electrostatic Unit of Current
Loop Current Operating Modes
Mode Description Loop Current in mA (Point to Point) Loop Current in mA (Multi-drop)
0 Healthy 4 mA 4 mA
1 Optical Fault 1 mA 4 mA
2 Non-Optical Fault 1 mA 4 mA
3 Alarm 20 mA 4 mA
Operating Mode
Power On 0
Non-Recovery Fault 1
Inhibit 2
Alarm 3
Fault 4
Warning 5
Normal 6
Alarm 16
Verified Alarm 17
Login Level
0 Dafault
1 Level 1
2 Level 2
