Honeywell Gamewell FCI S3 Series - 2: SLP-E3 Main Board Outputs; Supplementary Circuits

16 S3 Series UL Listing Document — P/N LS10005-051GF-E:D3 3/09/2016
Installation Wiring Supplementary Circuits
Table 2.4.1.1 lists the Notification Appliance Circuit specifications.
2.4.2 SLP-E3 Main Board Outputs
The SLP-E3 provides output for a Local Energy City Master Box, Reversing Polarity Output for leased line
connection Service. Table 2.4.2.1 lists the SLP-E3 main board outputs.
2.5 Supplementary Circuits
N/A
Requirements NACs Specifications
Circuit Supervision: Supervised
Power-Limited: Class 2 Power-Limited
Type of signaling devices and connection, if
polarized, indicate proper wiring with plus or
minus (+-) symbols, or equivalent for proper field
connection.
Refer to Figure 2.4.1.1.
Max. current, rated voltage and frequency: 2.0 amps per circuit not to exceed a total of 6.5
amps on all circuits.
Identifying circuit with rating designation. Identify
appliances/devices by manufacturer’s name,
model and max. # of devices/circuit.
Refer to the Compatibility Addendum to
Gamewell-FCI Manuals, P/N: 9000-0427-L8-L8.
Max. RMS operating current for any single NAC
appliance, where sync. NAC appliances not
employed.
Refer to the Compatibility Addendum to
Gamewell-FCI Manuals, P/N: 9000-0427-L8-L8.
Each NAC, identify if synchronized NAC
appliance are permitted. If synchronized NAC
appliances employed, specify max. # per circuit if
# exceeds loading calculations.
2.0 amps/circuit
Full-wave rectified voltages identified: Uses filtered DC voltages.
EOL Resistor Part Number or value: 6.2 K - 47 K, 1/4 W or higher, -or-
3.2 K - 6.2 K, 1/2W or higher, -or-
1.5 K - 3.2 K, 1W or higher.
Identified by Class or by Class/Style: Two 24 VDC Class A, Style Z or four Class B,
Style Y notification appliance circuits.
Impedance values for testing at which ground
faults are annunciated.
Zero Ohms
For each NAC, identify if synchronized NAC
appliances are permitted. If synchronized NAC
appliances employed, specify max. # per circuit if
# exceeds leading calculations.
Refer to the Compatibility Addendum for
Gamewell-FCI Manuals, P/N: 9000-0427-L8-L8.
Notification Appliance Circuit (NAC), Addressable
NAC circuits using AOM-2FS or MMO-6SF
modules:
Refer to Section 2.6.1(Signaling Line Circuit
Wiring and Ratings)
Table 2.4.1.1 Notification Appliance Circuit Specifications
Ratings Master Box (NPL) Polarity Reversal (PL) Releasing Service
Nominal Voltage 24 VDC 24 VDC 24 VDC
Supervisory Current: .0018 amp .012 amp .0005 amp
Alarm Current: .510 amp (max.) .012 amp .700 amp
Line Resistance 35 Ohms (max.) 2 Ohms (max.)
Trip Coil Resistance 14.5 Ohms (max.)
Table 2.4.2.1 SLP-E3 Main Board Outputs
