S3 Series UL Listing Document — P/N LS10005-051GF-E:D3 3/09/2016 55
Section 8: System Configuration
8.1 S3 Series System Listed Service Type Applications
Table 8.1.1 includes the service type applications Listed for the S3 Series System.
8.2 S3 Series System Configuration
Table 8.2.1 lists the minimum S3 Series System configuration.
Type of Service Model
IDC
Class
Initiating
Device Type
NAC
Class
Type
Signaling
Signal Line
Circuit
Local SLP N/A A, M, WF, SS A, B NC, M Styles 4, 6, 7
Auxiliary SLP N/A A, M, WF N/A N/A Styles 4, 6, 7
Remote Station (PPU)
(See Note 1)
SLP N/A A, M, WF N/A
Polarity
Reversal
Styles 4, 6, 7
Remote Station (PPU)
(See Note 1)
SLP N/A A, M, WF, SS N/A DACT, OT Styles 4, 6, 7
Proprietary (PPU) SLP N/A A, M, WF, SS N/A DACT, OT Styles 4, 6, 7
Proprietary (PPU) SLP N/A A, M, WF, SS N/A (See Note 2) Styles 4, 6, 7
Central Station (PPU)
(See Note 1)
SLP N/A A, M, WF, SS N/A DACT, OT Styles 4, 6, 7
Releasing SLP N/A A, M, WF, SS A, B M, NC Styles 4, 6, 7
NOTE 1: The designated service type used when the product is equipped with the DACT-E3 sub-
assembly for DACT Type Signaling. When equipped with both DACT-E3 and separately Listed
model IPDACT-2 for OT Type Signaling.
NOTE 2: The designated service type employs peer-to-peer network sharing information. Any
SLC-PM or SLC95-PM node so designated is acceptable as a Proprietary PPU.
Table 8.1.1 S3 Series, Service Type Applications
Accessory/
Sub-Assembly
Part Number Description Local Remote
Station
(Rev.Pol.)
Proprietary Auxiliary Remote
Station
(DACT)
Releasing
Service
(Preaction/
Deluge)
SLP
SLP-RB
Smart Loop Panel -
Main Board
Yes Yes Yes Yes Yes Yes
SLC-PM SLC-PM SLC-PM for System
Sensor Protocol
Yes Yes Yes Yes Yes Yes
SLC95-PM SLC95-PM SLC95-PM for Apollo
Protocol
Yes Yes Yes Yes Yes Yes
LCD-E3 LCD-E3
LCD Display
OO O O O O
LCD-SLP
LCD-SLP
LCD Display-SLP
Yes Yes Yes Yes Yes Yes
FLPS-7
FLPS-7-RB
Power Supply Yes Yes Yes Yes Yes Yes
RPT-E3-UTP
RPT-E3-UTP
Network Repeater OO O O O O
FML-E3
FML-E3 Fiber-Optic Multi-Mode
OO O O O O
FSL-E3
FSL-E3 Fiber-Optic Single-Mode
OO O O O O
DACT-E3 DACT-E3
Digital Dialer
Communicator Transmitter
No No Yes Yes Yes O
ASM-16
1100-0455
Annunciator Switch OO O O O O
ANU-48
1100-0503
Annunciator OO O O O O
LCD-7100
1100-0399 Remote LCD Display
OO O O O O
RAN-7100
RAN-7100 Remote LCD Display
OO O O O O
NOTE 1: Y = Yes, N = No, and O = Optional.
Table 8.2.1 Minimum S3 Series System Configuration
