30 Series Network Video Recorder User Guide
18
Working with the PTZ Control Panel (If Applicable)
You can control a PTZ camera connected to the NVR through a network connection using the
on-screen PTZ control panel on the camera tool bar.
PTZ Control Panel
Figure 3-6 PTZ Control Panel
Table 3-3 PTZ Controls
Name Function
PTZ control
Click and drag the circle in the center towards the direction
you wish to move to.
Focus
Click the Focus near and Focus far buttons to adjust camera
focus.
Home
Click to move the camera lens towards the default home
position.
Zoom
Use the Zoom in and Zoom out buttons to adjust the camera's
zoom ratio.
