30 Series Network Video Recorder User Guide
32
Figure 6-4 Add A Camera by RTSP
1. Select an empty camera entry.
2. Select Connection type and Port according to the below table:
Table 6-1 Connection Type and Port
Connection type Port
HTTPS 443
HTTP 80
TCP 554
3. Enter IP address in the IP field.
4. Select RTSP in the Protocol field and enter "live.sdp" in the URL field.
The original RTSP address is: rtsp://<ip address>:<rtsp port>/<access name for stream 1
to 3>. For example, when the access name for stream 1 is set to live.sdp, the original RTSP
is: rtsp://192.168.5.151:554/live.sdp.
The system automatically fills in the other parameters.
5. Click Apply.
Note
• RTSP cameras do not support event recording in the Schedule
settings.
• RTSP cameras do not support FTP, Camera DO, and PTZ as the Alarm
action.
• RTSP cameras do not support camera's related settings such as
Network, Video, Audio, and Display configurations.
• RTSP cameras will be indicated by an RTSP tag in the device list.
• RTSP cameras do not support Motion detection configuration.
