INNCOM e7w THERMOSTAT USER GUIDE
31-00302-01
4
Specifications
Mounting
Standard US — Double Gang: Without Spacer Ring
Standard US — Single Gang: Without Spacer Ring
Standard UK — Single Gang: Without Spacer Ring
Dimension
L 120 mm x W 120 mm x H 23 mm (without spacer ring)
{L 4.7 inch x W 4.7 inch x H 0.90 inch (without spacer ring)}
Ambient Operating
41 to 149 ° F (5 to 40 ° C), 0-95% RH non-condensing
Ambient Storage
33 to 149 ° F (1 to 65 ° C), 0-95% RH non-condensing
In room Temperature
60 to 85° F (± 1° F) / 15 to 30° C (± 0.5° C)
Power
Input: 6VDC (Four AA Batteries of 1.5VDC each)
Output: N/A
Color Variants
Ice White and Black Onyx
Display resolution
High Twisted Nematic (HTN) LCD, 0.5 °C (0.1 °F in test
mode).
Standard dead band
2 ° F (1° C) between heating and cooling.
Thermostat Measurement range
33 to 99 ° F (1 to 37 ° C) +/- 1.8 ° F.
Outdoor air temperature display
0 to 99 °F (-18 to 37 °C) as reported from web service
Motion sensor
120° View Angle, 10meter line of sight
Light Sensor
Gamma Value 0.7, Spectral response 550 – 650 nm.
Humidistat
3 % RH., in range from 30-95 % RH., +/- 5% RH. outside this
range.
Frequency range
2405MHz to 2480MHz
Maximum power
7dBm
Hardware version
A
