c) After receiving the Forward Bind Request, the target device flashes LED confirm-
ing that it receives the Forward Bind Request.
• For binding RF devices, press bind button on the target device two
times quickly, then press and hold bind button for 5-7 seconds to ac-
cept the bind request.
• For binding Non-RF devices, press bind button once on the target de-
vice to accept the bind request.
d) After accepting the new I/O Map, the target device RESET and send message to
e7w to make it sounds its audible buzzer.
e) After receiving the message, e7w beep three times to confirm the binding.
7. Press the FC button to return SERVICE MODE or press UP arrow button to display
next mode.
Or
Press the FC button twice to exit SERVICE MODE
NOTE: For more details, refer applicable commissioning document.
