160 Thor VM1 with Microsoft Windows Embedded Standard 2009 User Guide
Factory Default Settings
The Main tab displays information about the wireless client device including:
• SCU (Summit Client Utility) version
• Driver version
• Radio Type (ABGN is an 802.11 a/b/g/n radio).
•Regulatory Domain
• Copyright Information can be accessed by tapping the About SCU button
• Active Config profile / Active Profile name
• Status of the client (Down, Associated, Authenticated, etc.).
The Active Profile can be switched without logging in to Admin mode. Selecting a differ-
ent profile from the drop down list does not require logging in to Administrator mode.
The profile must already exist. Profiles can be created or edited after the Admin login
password has been entered and accepted.
When the profile named “ThirdPartyConfig” is chosen as the active profile, the Summit
Client Utility passes control to Wireless Manager for configuration of all client and
security settings for the network module.
The Disable Radio button can be used to disable the network card. Once disabled, the
button label changes to Enable Radio. By default the radio is enabled.
The Admin Login button provides access to editing wireless parameters. Profile and
Global may only be edited after entering the Admin Login password.
The password is case-sensitive.
Once logged in, the button label changes to Admin Logout. To logout, either tap the
Admin Logout button or exit the SCU without tapping the Admin Logout button.
Admin Login SUMMIT
Radio Enabled
Active Config/Profile Default
Regulatory Domain FCC, ETSI or Worldwide
