Thor VM1 with Microsoft Windows Embedded Standard 2009 User Guide 11
VMXD Enhanced Dock for Off-Vehicle Use
Caution: This dock is designed for AC power (non vehicle-mounted)
applications only.
SKU VMX005VMCRADLE
Power
Connection
AC/DC Adapter
Serial Ports COM1 and COM2
USB Ports USB1 port provides host connection via an adapter cable.
USB2 port provides two USB host ports via an adapter cable.
Direct USB host connection on top of dock.
Ethernet RJ-45 Ethernet connection on top of dock.
Note: The Ethernet port is not supported with the Windows Embedded Standard 2009
operating system.
CANbus CANbus connection via an adapter cable
Audio Headset connection via an adapter cable
Screen
Blanking
Supported via COM1 and COM2 connectors.
Ignition
Control
Not supported
