VM3D Enhanced Dock
Caution: This dock is designed for DC power vehicle-mounted
applications only.
SKU VM3001VMCRADLE
Power
Connection
Direct or DC/DC power supply
Serial Ports COM1 and COM2
USB Ports USB1 port provides host connection via an adapter cable.
USB2 port provides two USB host ports via an adapter cable.
Direct USB host connection on top of dock.
Ethernet RJ-45 Ethernet connection on top of dock.
Note: The Ethernet port is not supported with the Windows Embedded Standard 2009
operating system.
CANbus CANbus connection via an adapter cable
Audio Headset connection via an adapter cable
Screen
Blanking
Supported via COM1 and COM2 connectors.
Ignition
Control
Supported
