Thor VM1 with Microsoft Windows Embedded Standard 2009 User Guide 115
Install SIM Card
A SIM card may be required for WWAN.
Note: The SIM card is not hot-swappable. After installing or removing a SIM card, the Thor VM1
must be rebooted for the change to take effect.
Equipment Required
The following equipment is user-supplied:
• SIM card for desired carrier
• Torquing tool capable of measuring inch pounds
• #2 Phillips screwdriver bit
1. For convenience, the Thor VM1
can be removed from the dock,
though it is not necessary.
2. If the Thor VM1 remains in the
dock, disconnect the power cable
from the dock.
3. Shutdown the Thor VM1.
4. Place the Thor VM1 face down on a
stable surface.
5. Using a #2 Phillips bit loosen the
M3 screws and then remove the
tethered access panel with the SIM
label. This panel is on the right
hand side when the Thor VM1 is face down with the top away from the user.
6. Locate the SIM card installation slot, as highlighted to the right.
7. Slide the SIM card into the slot.
Note: The entire SIM slot is not visible due to the design of the Thor VM1 case. However, the
entire slot is shown below to help with installation.
