232 Thor VM1 with Microsoft Windows Embedded Standard 2009 User Guide
VM1D Standard Dock
Caution: This dock is designed for DC power vehicle-mounted
applications only.
SKUs VM1001VMCRADLE (with RAM ball)
VM1002VMCRADLE
VM1003VMCRADLE
Power Connector 6-pin connector:
Direct10-60V DC input power
Optional external converter for extended range DC (60-150 VDC)
COM1Connector 9-pin male, RS-232 serial port, COM1 with power on pin 9
COM2 Connector 9-pin male, RS-232 serial port, COM2 with power on pin 9
CANBUS/AUDIO Connector 15-pin male, CANbus/Audio connector supports either audio/microphone via adapter cable or
J1939 Female and J1939 Male connectors via CANbus cable
USB Connector 9-pin female, USB connector supports USB host port via adapter cable
Power Switch Sealed power switch
Input Power DC Input Voltage: 10- 60 VDC,
Input Current: 4.6 Amps (typical),
Input Fuse: 8A Time Delay. Replace with same size, rating and type of fuse:
• Littelfuse 0215008.MXP
• Cooper Bussmann BK1/S506-8-R
• Bel Fuse 5HT 8-R
or equivalent.
External Power Supply 50-150 VDC DC power supply available for vehicles over 60 VDC
Note: Use dock VMX005VMCRADLE (VMXD Enhanced Dock of Off-Vehicle Use) in AC power
applications.
