VM3D Enhanced Dock
Caution: This dock is designed for DC power vehicle-mounted
applications only.
SKU VM3001VMCRADLE
Power Connector 6-pin connector:
Direct10-60V DC input power
Optional external converter for extended range DC (60-150 VDC)
COM1Connector 9-pin male, RS-232 serial port, COM1 with power on pin 9
COM2 Connector 9-pin male, RS-232 serial port, COM2 with power on pin 9
CANBUS/AUDIO Connector 15-pin male, CANbus/Audio connector supports either audio/microphone via adapter cable or
J1939 Female and J1939 Male connectors via CANbus cable
USB1 Connector 9-pin female, USB connector supports USB host port via adapter cable
Note: USB Client port may not be supported by the Thor VM1 operating system.
USB2 Connector 15-pin female, USB connector supports two USB host ports via adapter cable
USB Host Connector One USB Host connector behind waterproof cap
Ethernet One RJ45 Ethernet connector behind waterproof cap
Note: The Ethernet port is not supported with the Windows Embedded Standard 2009
operating system.
Power Switch Sealed power switch
Input Power DC Input Voltage: 10- 60 VDC,
Input Current: 4.6 Amps (typical),
Input Fuse: 8A Time Delay. Replace with same size, rating and type of fuse:
• Littelfuse 0215008.MXP
• Cooper Bussmann BK1/S506-8-R
• Bel Fuse 5HT 8-R
or equivalent.
External Power Supply 50-150 VDC DC power supply available for vehicles over 60 VDC
Note: Use dock VMX005VMCRADLE (VMXD Enhanced Dock of Off-Vehicle Use) in AC power
applications.
