224 Thor VM1 with Microsoft Windows Embedded Standard 2009 User Guide
Information Buttons
SMS
The SMS button is enabled if no Internet connection is active. When this button is active,
tapping it accesses the integrated SMS application.
Web
Tap this button to launch the default browser.
Email
Tap this button to launch the default Email application.
GPS
Tap this button access the integrated GPS tool.
Icon Description
Icon Description
Radio On/Off
Tap this button to switch the radio state. The color of this button also indicates the state of the
radio:
The radio is On. Tap the button to turn the radio Off.
The radio is Off. Tap the button to turn the radio On.
The radio is Connecting or the radio has been disabled. The button is inactive at this time.
Statistics Show/Hide
Tap the button to expand the screen to include connection statistics. See Statistics Button
for details.
Tap the button to hide the connection statistics.
Settings
Tap this button to access One Clink Internet settings. Select from several tabs to configure the
connection settings. See Settings Button for details.
Update
Tap this button to access OneClick Internet Update tab. See Update Button.
Help
Click this button to view the online help.
Status
Ready. Tap the Connect button to establish a connection.
Connecting. Tap the Cancel button to cancel the connection in process.
Connected. Tap the Disconnect button to end the connection.
Failure. Review the screen for messages such as “No Network”, etc.
