Resource
Value
%S
13
%SR
192
%T
2048
%M
2048
%R
9999
%K
10
%D
1023
%I
2048
%Q
2048
%AI
512
%AQ
512
%IG
64
%QG
64
%AIG
32
%AQG
32
Network
Ports
CsCAN
(Optional depend
ing on mod
e
l.)
Controllers
Per Network
253
Keypad
20 keys (10 fn k
eys and 4 soft keys) for XLE
5
fn
keys for XLT
Display
128x64 LCD Ba
c
klit, mon
oc
hrome for XLE
160x128 LC
D Backlit, mo
nochrome for XLT
Screen
Memory
1M
User Screens
1023
Data Fields
Per User
Screen
50
Ladder Code
256k
111
113
