15.3 Cscape Status Bar
When the XLE/XLT is connected to a PC using Cscape software a Status Bar appears at the
bottom of the screen. The Cscape Status Bar can be used to determine if communications have
been established between the XLE/XLT and the Cscape program. Components of the Cscape
Status Bar are explained below.
Ready
User: NONE
HE-XExx1-CsCAN (Model=)
Equal
Local :1 Target :2(R) [no
forces]
MOD
Equal Indicator – indicates whether the current program in Cscape is equal to the program
stored in the Target Controller.
•
If Equal
, the program in Cscape is the same as the program stored in the Target Controller.
•
If Not Equal
, the program in Cscape is not the same as the program stored in the Target
Controller.
•
If Unknown,
there may have been a change since the last time the program in Cscape was
compared to the Target Controller.
Communications Status - indicates the current status of the
“pass through” Connector.
•
Local: xx – indicates the Network ID of the XLE/XLT to
which the Cscape program is physically connected through
its serial port. It can serve as a pass-through device to other
nodes on the network.
•
Target: yy(R)
– indicates the Network ID of the device with
which the Cscape program is exchanging data.
NOTE: The Local unit and Target unit can be the
same unit, or they can be separate units.
The following are status indicators:
(R) – Running
(D) - Do I/O
(I) – Idle
(?) – Cscape is not communicating with the remote unit.
[no forces] – indicates no I/O has been forced.
Message Line -
The contents of
these messages
are context
sensitive. The
Message line can
be empty.
Current User -
indicates who is logged
(for security purposes).
Controller Model – Network (Model Confirmation)
•
Controller Model indicates the controller model for
which the program in Cscape is configured.
•
Network
indicates the type of network that the program
in Cscape expects to use (e.g., CsCAN).
•
(Model Confirmation) provides the following
indications:
•
(Model=) - The actual Target Controller matches the
configured Controller Model and Network.
•
(Model Not=) – The actual Target Controller does not
match the configured Controller Model and Network.
•
(Model ?)
– There may have been a change since the
last time the Target Controller was compared to the
configured Controller Model and Network.
File Modified Indicator - indicates that the file in
the selected window has been modified but has
not been saved.
