HORNER XLE-Model 2 User Manual

MAN0878-09-EN_XLE_XLT_UserManual
A u g u s t 2 3 , 2 0 1 8 P a g e 41 | 158
CHAPTER 8: ETHERNET COMMUNICATION
8.1 Ethernet Module Protocols and Features
The following table describes the Ethernet Module protocols and features supported by the
Ethernet port on the XLEe/XLTe:
Table 8.1 – Ethernet Module Protocols / Features
Protocol / Feature
Protocol / Feature Description
ICMP Ping
Internet Control Message Protocol
EGD (Peer to Peer)
Ethernet Global Data
SRTP Server
Service Request Transfer Protocol
CsCAN TCP Server
Horner APG CsCAN over Ethernet
Modbus TCP Slave
Modbus over Ethernet
Ethernet / IP Server
ODVA CIP over Ethernet
FTP Server
File Transfer Protocol
ASCII Over TCP/IP
ASCII Data over Ethernet
8.2 Ethernet System Requirements
Full Ethernet functionality requires:
- PC running Cscape Programming Software Version 9.8 or later (for configuration).
- XLE/XLT controller with onboard Ethernet port.
8.3 Ethernet Module Specifications
Table 8.2 – Ethernet Module Specifications
Speeds
10 BaseT Ethernet (10Mbps)
100 BaseTx Fast Ethernet (100Mbps)
Modes
Half or Full Duplex
Auto-Negotiation
Both 10/100Mbps and Half/Full Duplex
Connector Type
Shielded RJ-45
Cable Type
(Recommended)
CAT5 (or better) UTP
Port
Auto MDI/MDI-X (Auto Crossover)
