16.2 Settings
To use the Fail – Safe feature, the user must do the following:
1. Backup the current Battery-Backed RAM Register contents in On-Board Flash memory
using System Menu options.
2. From Cscape, create AUTOLOAD.PGM for the application program using ‘Export to
Removable Media’.
3. Place the Removable Media with AUTOLOAD.PGM in the device.
4. Set the ‘Enable AutoLoad’ option in the device to YES.
5. Set the ‘Enable AutoRun’ option to YES if the controller needs to be placed in RUN
mode automatically after automatic restore of data or AutoLoad operation.
16.3 Backup / Restore Data
Selecting this option brings up a screen having four operations:
• Backup OCS Data.
• Restore OCS Data.
• Clear Backup Data.
• Exit
XLE:
XLT:
Figure 16.2 – Backup / Restore Data
