MAN0878-09-EN_XLE_XLT_UserManual
A u g u s t 2 3 , 2 0 1 8 P a g e 68 | 158
10.10 Removable Media (RM) Features—Graphic/Screen Editor
a. Trends—The historic support feature in the trend object utilizes Removable Media.
b. Removable Media—This is a graphic object used to access files and functions pertaining to
Removable Media.
c. Recipes—This is a graphic object that is used in conjunction with the recipe editor which is
mentioned above.
10.11 Removable Media (RM) Features—Additional Configuration
a. Alarms—Alarm data can be logged to a .csv file stored on Removable Media.
b. Screen Capture—The screen capture function allows a bitmap or jpeg image of the displayed
OCS screen to be written to the Removable Media card.
c. Filename Counters— The filename counters can be accessed wherever Removable Media
functions require a path name. A typical application is the auto-incrementing of a file name
when doing screen captures.
d. File Select— File Select is used to specify the register block that is used with the Removable
Media Manager object ‘Write Selected Filename’ option.
