Please see the Cscape Help file for more detailed information.
Table 7.1 – Network Protocols
Baud Rate, Data Bits, Stop Bits,
Parity
These field define the bit level transfer over the serial port.
Handshake
None – No handshake lines are used
Multidrop Full – Rx remains active while Tx is occurring.
Multidrop Half – Rx is shut off while Tx is occurring.
Radio Modem – Wait for CTS acknowledgement before
transmitting (legacy radio modem support).
Protocol
If a driver supports multiple protocols, it is selected here, (i.e.
Modbus supports RTU or ANSI).
Mode
Specifies if port operates in RS232 or RS485 mode.
Retries
Specifies number of times a transaction is retried on a failed
response.
Timeout
Specifies the amount of time for a device to wait for a valid
response.
Update Scan
Automatic
Update Interval – Specifies the update interval at
which all the mapped entries are executed.
Reacquire Time – Specifies the amount of time to
wait before attempting communications with an
offline device.
Manual
Trigger – Specifies the binary register that a single
transaction scan of the Scan List.
ID Select – If an analog is specified in the field, the ID
Select filter is enabled.
Status Register
Specifies the starting OCS register of eight (8) consecutive
registers (4-32bit counters), which provide an indication of the
network health.
Scanner Address
Specifies the OCS’s device (network) ID if a master ID is required
by the protocol.
Protocol Help
Provides protocol specific help.
