HP 5920 Series Configuration Guide

55
Configuration procedure
1. Configure the LDAP server:
NOTE:
In this example, the LDAP server runs Microsoft Windows 2003 Server Active Directory.
# Add a user named aaa and set the password to ldap!123456.
a. On the LDAP server, select Start > Control Panel > Administrative Tools.
b. Double-click Active Directory Users and Computers.
The Active Directory Users and Computers window is displayed.
c. From the navigation tree, click Users under the ldap.com node.
d. Select Action > New > User from the menu to display the dialog box for adding a user.
e. Enter the login name aaa and click Next.
Figure 17 Adding user aaa
f. In the dialog box, enter the password ldap!123456, select options as needed, and click Next.
