HP 5920 Series Configuration Guide

69
Figure 30 802.1X authentication procedure in EAP termination mode
In EAP termination mode, the network access device rather than the authentication server generates an
MD5 challenge for password encryption. The network access device then sends the MD5 challenge
together with the username and encrypted password in a standard RADIUS packet to the RADIUS server.

HP 5920 Series Specifications

General

Brand	HP
Model	5920 Series
Category	Switch
Language	English
