DRAFT - HP Confidential - DRAFT
Removal and replacement procedures 100
5. Disconnect the front I/O module cable.
6. Remove the front I/O board.
To replace the component, reverse the removal procedure.
System board
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
CAUTION: To prevent damage to electrical components, take the appropriate anti-static
precautions before beginning any installation, removal, or replacement procedure. Improper
grounding can cause electrostatic discharge.
