HP Apollo 4200 Gen9 Maintenance And Service Guide

DRAFT - HP Confidential - DRAFT
Illustrated parts catalog 6
Illustrated parts catalog
Mechanical components
HP continually improves and changes product parts. For complete and current supported parts information,
see the HP PartSurfer website (http://partsurfer.hp.com).
Item
Description
Spare part
number
Customer self
repair
1
Air baffle
813583-001
Mandatory
1
2
Fan cage cover
813582-001
Mandatory
1
3
Miscellaneous Blanks Kit
809955-001
Mandatory
1
a) PCI expansion slots 5-7 cover air blocker
—
Mandatory
1
b) Chassis retention brackets
—
Mandatory
1
c) Fan blank
—
Mandatory
1
d) LFF drive blank (reduced depth)
—
Mandatory
1
e) SFF drive blank
—
Mandatory
1
f) Air flow blocker for front drive cage 2
—
Mandatory
1
g) Cable management holder
—
Mandatory
1
h) FlexibleLOM slot blank
—
Mandatory
1
i) Chassis rear bracket
—
Mandatory
1
