HP Apollo 4200 Gen9 Maintenance And Service Guide

DRAFT - HP Confidential - DRAFT
Removal and replacement procedures 32
Open the cable management holder
1. Power down the server (on page 17).
2. Remove the server from the rack (on page 27).
3. Remove the access panel ("Access panel" on page 36).
4. Remove the air baffle ("Air baffle" on page 37).
5. Pull down the front drive cage release latches and use them to completely extend the front drive cages
from the chassis.
6. Disconnect all system cables secured in the cable management holder from the system board or
controller board, and then release them from the holder.
