HP Apollo 4200 Gen9 Maintenance And Service Guide

DRAFT - HP Confidential - DRAFT
Component identification 131
Item
Description
3
PCIe3 x16 (16, 8, 4, 1) slot 5 for low-profile, standup expansion
board
2
4
PCIe3 x8 (8, 4, 1) riser slot 3 for full-height, half-length expansion
board
1
5
PCIe3 x8 (8, 4, 1) riser slot 4, full-height, half-length expansion
board
1
6
PCIe3 x16 (16, 8, 4, 1) slot 2 for low-profile, standup expansion
board or riser cage options
1
7
PCIe3 x8 (8, 4, 1) slot 1 forlow-profile, standup expansion board
1
8
FlexibleLOM slot
9
Hot-plug power supply 1
10
Hot-plug power supply bay 2
11
USB 3.0 connectors
12
NIC 1/shared iLO connector
13
NIC connector 2
14
Video connector
15
Dedicated iLO management connector (optional)
1
PCIe connectors 1-4 are associated with processor 1.
2
PCIe connectors 5-7 are associated with processor 2.
Rear panel LEDs
Item
Description
Status
1
Dedicated iLO
activity LED
Solid green = Link to network
Flashing green = Network active
Off = No network activity
2
Dedicated iLO link
LED
Green = Network link
Off = No network link
3
NIC activity LED
Solid green = Link to network
Flashing green = Network active
Off = No network activity
4
NIC link LED
Green = Network link
Off = No network link
