Removal and replacement procedures 37
Air baffle
To remove the component:
1. Power down the server (on page 17).
2. Remove the server from the rack (on page 27).
3. Remove the access panel ("Access panel" on page 36).
4. If an HP Smart Storage Battery is installed on the air baffle, disconnect the battery cable.
5. Remove the air baffle.
To replace the component, reverse the removal procedure.
Four-bay LFF hot-plug rear drive backplane
