DRAFT - HP Confidential - DRAFT
Removal and replacement procedures 34
3. Pull and hold the drive cage rail release latches, and then slide the front drive cages back into the
chassis.
4. Install the air baffle.
5. Install the access panel.
6. Install the server into the rack.
7. Power up the server.
Hot-plug drive blank
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless
all bays are populated with either a component or a blank.
To remove the component:
1. If installed, remove the security bezel (on page 24).
2. Remove the drive blank.
To replace the LFF drive blank, slide the component into the bay until it clicks.
