DRAFT - HP Confidential - DRAFT
Removal and replacement procedures 114
— Two-bay SFF hot-plug rear drive cage removal ("Hot-plug drive" on page 35, "Remove a drive
from the rear drive cage" on page 26)
6. Remove the dedicated iLO management module.
To replace the component, reverse the removal procedure. After installing the new dedicated iLO
management module, enable the dedicated iLO connector ("Enabling the dedicated iLO management
module" on page 114).
Enabling the dedicated iLO management module
The onboard NIC 1/shared iLO connector is set as the default system iLO connector. To enable the
dedicated iLO management module, use the iLO 4 Configuration Utility accessible within the HP UEFI System
Utilities.
For more information on the HP UEFI System Utilities, see the UEFI documentation on the HP website
(http://www.hp.com/go/ProLiantUEFI/docs).
