Cabling 144
M.2 SSD enablement board installed in the onboard PCIe3 x16 slot 2
Item
Description
1
M.2 SSD 1 SATA cable
2
M.2 SSD 2 SATA cable
M.2 SSD cabling from the PCI riser cage
Item
Description
1
M.2 SSD 1 SATA cable
2
M.2 SSD 2 SATA cable
FBWC module backup power cabling
The FBWC solution is a separately purchased option. This server only supports FBWC module installation
when an HP Smart Array P-Series controller is installed.
Depending on the controller option installed, the actual storage controller connectors might look different
from what is shown in this section.
