DRAFT - HP Confidential - DRAFT
Removal and replacement procedures 116
5. Pull down the front drive cage release latches and use them to completely extend the front drive cages
from the chassis.
6. Remove the power pass-through module.
To replace the component, reverse the removal procedure.
AC power supply
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless
all bays are populated with either a component or a blank.
To remove the component:
1. Power down the server (on page 17).
