Page #11 background imageLoading...
Page #11 background image
DRAFT - HP Confidential - DRAFT
Illustrated parts catalog 11
Description
Spare part
number
Customer self
repair
Dedicated iLO management module
809944-001
Optional
2
System board (include alcohol pad and thermal
compound)
809943-001
Optional
2
4-bay LFF rear drive backplane
809949-001
Optional
2
2-bay SFF rear drive backplane
809950-001
Optional
2
HP P840ar Smart Array Controller board
813586-001
Optional
2
System cables*
a) Signal and power cables for 12-bay LFF front drive
cage 1 and cage 2*
809956-001
Optional
2
b) Signal and power cables for 24-bay SFF front drive
cage 1 and cage 2*
813584-001
Optional
2
c) Cable kit*
810246-001
Mandatory
1
i) 2-SFF multi-connector drive signal cable*
ii) Power Y-cable for 2-SFF or 4-LFF rear drive*
iii) Ambient temperature sensor cable*
iv) Mini-SAS cable*
* Not shown
1
MandatoryParts for which customer self repair is mandatory. If you request HP to replace these parts, you will be
charged for the travel and labor costs of this service.
2
OptionalParts for which customer self repair is optional. These parts are also designed for customer self repair. If,
however, you require that HP replace them for you, there may or may not be additional charges, depending on the type
of warranty service designated for your product.
3
NoSome HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires that
an authorized service provider replace the part. These parts are identified as "No" in the Illustrated Parts Catalog.
1
Mandatory: ObligatoirePièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP de
remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés.
2
Optional: FacultatifPièces pour lesquelles la réparation par le client est facultative. Ces pièces sont également
conçues pour permettre au client d'effectuer lui-même la réparation. Toutefois, si vous demandez à HP de remplacer ces
pièces, l'intervention peut ou non vous être facturée, selon le type de garantie applicable à votre produit.
3
No: NonCertaines pièces HP ne sont pas conçues pour permettre au client d'effectuer lui-même la réparation. Pour
que la garantie puisse s'appliquer, HP exige que le remplacement de la pièce soit effectué par un Mainteneur Agréé. Ces
pièces sont identifiées par la mention ―Non‖ dans le Catalogue illustré.
1
Mandatory: ObbligatorieParti che devono essere necessariamente riparate dal cliente. Se il cliente ne affida la
riparazione ad HP, deve sostenere le spese di spedizione e di manodopera per il servizio.
