HP Apollo 4200 Gen9 Maintenance And Service Guide

DRAFT - HP Confidential - DRAFT
Component identification 133
Item
Description
3
PCIe3 x16 (16,8,4,1) slot 2 for low-profile, standup expansion
board or riser cage options
1
4
microSD slot
5
TPM connector
6
HP Flexible Smart Array Controller slot
7
Dedicated iLO management module connector
8
PCIe3 x16 (16, 8, 4, 1) slot 5 for low-profile, standup expansion
board
2
9
PCIe3 x8 (8, 4, 1) slot 6 for low-profile, standup expansion board
2
10
PCIe3 x16 (16, 8, 4, 1) slot 7 for low-profile, standup expansion
board
2
11
NMI header
12
Storage backup power connectors for expansion slots 3–7
13
Front I/O connector
14
Processor 2 DIMM slots
15
Processor 1 DIMM slots
16
System battery
17
Fan signal connector
18
HP Smart Storage Battery connector
19
Rear SFF drive backplane detection connector
20
Fan power connector
21
Front drive cage 2 backplane power connector
22
Front drive cage 1 backplane power connector
23
Storage backup power connector for expansion slots 1–2
24
SATA 6Gb/s connector 4
25
SATA 6Gb/s connector 5
26
Power pass-through board connector
27
Internal USB 3.0 connector
28
SATA x4 connector 1
29
Rear drive cage backplane power connector
30
Front USB 2.0 connector
X
System maintenance switch
1
PCIe connectors 1–4 are associated with processor 1.
2
PCIe connectors 5–7 are associated with processor 2.
