DRAFT - HP Confidential - DRAFT
Removal and replacement procedures 56
o M.2 SSD SATA cable disconnection when the enablement board is installed on the system board
slot 1 or 2
o M.2 SSD SATA cable disconnection when the enablement board is installed in the PCI riser cage
8. Remove the M.2 SSD enablement board.
