DRAFT - HP Confidential - DRAFT
Removal and replacement procedures 78
2. Remove the server from the rack (on page 27).
3. Pull down the front drive cage release latches and use them to completely extend the front drive cages
from the chassis.
4. Remove the access panel ("Access panel" on page 36).
5. Remove the air baffle ("Air baffle" on page 37).
6. Open the cable management holder (on page 32).
7. Disconnect the front drive cage 1 and cage 2 power cables from the system board.
8. Remove the cable management holder.
