Part number Description Table and page
RC1-3490-000 Lock, lifter plate Cassette assembly
on page 223
RC1-3492-000 Spring, grounding Cassette assembly
on page 223
RC1-3507-000 Stopper, cassette right Cassette assembly
on page 223
RC1-3508-000 Stopper, cassette left Cassette assembly
on page 223
RC1-3535-000 Guide, shutter, rear Internal components (2 of 4)
on page 201
RC1-3541-000 Plate, drum grounding Internal components (4 of 4)
on page 207
RC1-3542-000 Lever, cartridge contact Internal components (4 of 4)
on page 207
RC1-3543-000 Spring, torsion Internal components (4 of 4)
on page 207
RC1-3546-000 Cam, right Internal components (2 of 4)
on page 201
RC1-3561-000 Arm lock Internal components (4 of 4)
on page 207
RC1-3562-000 Bushing Internal components (4 of 4)
on page 207
RC1-3563-000 Cover, drum Internal components (3 of 4)
on page 205
RC1-3565-000 Plate, drum grounding Internal components (3 of 4)
on page 205
RC1-3580-000 Stopper Internal components (2 of 4)
on page 201
RC1-3604-000 Side plate, fixing, right Fuser assembly on page 215
RC1-3605-000 Side plate, fixing, left Fuser assembly on page 215
RC1-3606-000 Plate, fixing reinforcement Fuser assembly on page 215
RC1-3607-000 Guide, fixing, upper Fuser assembly on page 215
RC1-3611-000 Guide, paper separate, lower Fuser assembly on page 215
RC1-3613-000 Flag, paper delivery sensor Fuser assembly on page 215
RC1-3614-000 Spring, torsion Fuser assembly on page 215
RC1-3615-000 Bushing Fuser assembly on page 215
RC1-3616-000 Lever, pressure release, right Fuser assembly on page 215
RC1-3617-000 Lever, pressure release, left Fuser assembly on page 215
RC1-3618-000 Lever, pressure-release sensor, right Fuser assembly on page 215
RC1-3619-000 Lever, pressure release sensor, left Fuser assembly on page 215
Table 8-19 Numerical parts list (continued)
240 Chapter 8 Parts and diagrams ENWW
