Part number Description Table and page
RM1-1283-000 Top sensor assembly Internal components (3 of 4)
on page 205
RM1-1291-000 Delivery frame assembly Fuser assembly on page 215
RM1-1295-000 Back end limit assembly Cassette assembly
on page 223
RM1-1296-000 Left paper side-end assembly Cassette assembly
on page 223
RM1-1297-020 Right paper side-end assembly Cassette assembly
on page 223
RM1-1298-000 Separation pad assembly Cassette assembly
on page 223
RM1-1301-000 Paper pick-up gear assembly Internal components (1 of 4)
on page 199
RM1-1305-000 Face-down gear assembly Assembly locations (1 of 2)
on page 191
RM1-1305-000 Face-down gear assembly Face-down gear assembly
on page 221
RM1-1321-000 Shutter link assembly Internal components (3 of 4)
on page 205
RM1-4159-000 Paper-sensor PCB assembly Internal components (3 of 4)
on page 205
RM1-4162-000 M.P. sensor PCB assembly Internal components (1 of 4)
on page 199
RM1-4163-000 Cable, memory tag Internal components (2 of 4)
on page 201
RM1-4169-000 Inlet/switch cable assembly Internal components (2 of 4)
on page 201
RM1-4244-000 Registration assembly Assembly locations (1 of 2)
on page 191
RM1-4244-000 Registration assembly Internal components (3 of 4)
on page 205
RM1-4245-000 Paper-width sensor assembly Internal components (3 of 4)
on page 205
RM1-4247-000 Fuser assembly (110 V) Assembly locations (2 of 2)
on page 193
RM1-4247-000 Fuser assembly (110 V) Fuser assembly on page 215
RM1-4248-000 Fuser assembly (220 V) Assembly locations (2 of 2)
on page 193
RM1-4248-000 Fuser assembly (220 V) Fuser assembly on page 215
RM1-4249-000 Film guide assembly (110 V) Fuser assembly on page 215
RM1-4250-000 Film guide assembly (220 V) Fuser assembly on page 215
RM1-4251-000 Cassette Assembly locations (1 of 2)
on page 191
Table 8-19 Numerical parts list (continued)
ENWW Numerical parts list 245
