CLI commands
welcome url
Supported on: MSM710
MSM730
MSM750
MSM760
MSM765zl
welcome url
<url>
Specifies the URL of a welcome page.
no welcome url
No welcome page.
notify user lo
cation changes
Supported on: MSM710
MSM730
MSM750
MSM760
MSM765zl
notify user location chan
ges
Notify RADIUS on location changes.
no notify user location c
hanges
Do not notify RADIUS on location chan
ges.
2-60
